Rated Capacity: 3000kg/3500kg
Load Center: 500m
| Specification | Unit | GFE 30 | GFE 35 |
|---|---|---|---|
| Модель | GFE 30 | GFE 35 | |
| Мощность Type | Battery | Battery | |
| Rated Capacity | kg | 3000 | 3500 |
| Load Center | mm | 500 | 500 |
| Lifting & Габариты | |||
| Lift Height | mm | 3000 | 3000 |
| Free Lift Height | mm | 130 | 130 |
| Fork Size (L*W*T) | mm | 1070×125×45 | 1070×125×45 |
| Fork Outside Spread (Min./Max.) | mm | 250/1100 | 250/1100 |
| Mast Tilt Range (F/R) | deg | 6/12 | 6/12 |
| Front Overhang | mm | 522 | 522 |
| Overall Length (Without Fork) | mm | 2680 | 2730 |
| Overall Length (With Fork) | mm | 3750 | 3800 |
| Wheel Width | mm | 1225 | 1225 |
| Mast Lowered Height | mm | 2085 | 2085 |
| Mast Extended Height | mm | 4180 | 4180 |
| Overhead Guard Height | mm | 2180 | 2180 |
| Радиус поворота | mm | 2460 | 2500 |
| Min. Right Angle Aisle Width | mm | 2105 | 2200 |
| Performance | |||
| Travel Speed (Unloaded/Full Load) | km/h | 18 | 18 |
| Lift Speed (Unloaded/Full Load) | mm/s | 300 | 300 |
| Self Weight | kg | 4300 | 4600 |
| Max. Преодоление уклонов | % | 15/15 | 15/15 |
