Rated Capacity:5000kg
Load Center:600
| Specification | Unit | GFE50 |
|---|---|---|
| Модель | GFE50 | |
| Мощность Type | Battery | |
| Rated Capacity | kg | 5000 |
| Load Center | mm | 600 |
| Lift Height | mm | 3000 |
| Free Lift Height | mm | 150 |
| Fork Size (L*W*T) | mm | 1220×150×70 |
| Fork Outside Spread (Min./Max.) | mm | 300/1830 |
| Mast Tilt Range (F/R) | deg | 6/12 |
| Front Overhang | mm | 590 |
| Overall Габариты | ||
| Overall Length (Without Fork) | mm | 3250 |
| Overall Length (With Fork) | mm | 4520 |
| Wheel Width | mm | 1490 |
| Mast Lowered Height | mm | 2400 |
| Mast Extended Height | mm | 4415 |
| Overhead Guard Height | mm | 2450 |
| Радиус поворота | mm | 3200 |
| Self Weight | kg | 8250 |
| Performance | ||
| Travel Speed (Unloaded/Full Load) | km/h | 18/18 |
| Lift Speed (Unloaded/Full Load) | mm/s | 500/550 |
| Max. Преодоление уклонов | % | 15 |
| Tires & Wheels | ||
| Tires (Front) | 8.25-15-14PR | |
| Tires (Rear) | 8.25-15-14PR | |
| Tread (Front) | mm | 1470 |
| Tread (Rear) | mm | 1700 |
| Wheelbase | mm | 2250 |
| Drive Units | ||
| Min. Дорожный просвет (Unload/Full Load) — Mast | mm | 190/160 |
| Min. Дорожный просвет (Unload/Full Load) — Frame | mm | 260/250 |
| Rated Мощность of Driving Motor (S2) | kW | 40 |
| Rated Мощность of Lifting Motor (S2) | kW | 30 |
| Operating Pressure | mpa | 17.5 |
| Battery (Optional) | V/Ah | 80V/600Ah |
